To achieve the best indoor climate control with PICVs it is important to use the best possible actuators. The faster and more accurate the actuator responds to the control signal, the better the result.
Danfoss offers a wide variety of actuators fitting the AB-QM Pressure-Independent balancing and Control Valve.For more information about NovoCon® digital actuators click here.
These innovative digital gear actuators are designed to be directly connected to Building Management Systems (BMS) using BACnet or Modbus bus-communication. This enables a whole new dimension to HVAC control, offering designers, system integrators and building owners many features and benefits.
For more information about NovoCon® digital IoT actuators click here.
Get the best out of modulating control with the 2nd generation AME 110NL/X for AB-QM 4.0 DN 15-32.
Erfahren Sie mehr
To achieve the best control performance with analog control signals, gear actuators should be used. These actuators control the position of the valve opening in a very accurate way.
AME gear actuators are controlled by a 0-10V or 4-20mA signal, while AMV actuators are controlled by a 3-point signal (open/neutral/close).
To achieve maximum control performance, geared actuators for AB-QM are equipped with automatic valve stroke detection.
Thermal actuators provide a cost-efficient control solution for the AB-QM valves. The basic principle of these actuators is based on thermal expansion of a wax element. TWA-Q actuators are controlled by an On/Off signal of a temperature controller, either heating the wax or not. The new TWA-Q is an IP54 actuator with extended stroke, fitting to all AB-QM and AB-QM 4.0 valves from sizes DN10 up to DN32.ABNM A5 actuators are controlled by a 0-10 Volt modulating signal of a temperature controller. The 0-10 V signal allows more accurate control possibilities.
Broad product range
With actuators available for all AB-QM dimensions (DN 10 – 250), for all commonly used control signals (on-off, 0-10V, 4-20 mA, bus communication) and functional principles (thermal, analog gear, digital gear), there is always an AB-QM / Actuator combination that corresponds to the project requirements.
We've asked some of our Global customers about their experience with AB-QM pressure independent balancing & control valves. Watch the video where they explain their benefits and why they have converted from conventional balancing solutions to PICVs.
Video abspielen
Updated September 2024
Infografik anzeigen
In Kürze verfügbar...
AME and AMV gear actuators with modulating and 3-point control for AB-QM and AB-QM 4.0 PICVs.
TWA-Q and ABNM A5 thermal actuators with on/off and 0-10V control for AB-QM and AB-QM 4.0 PICVs.
Our advanced Danfoss SET 365 3D design software will help you to design and calculate HVAC systems with Danfoss products. A 1-year subscription is FREE available for students, designers and other interested professionals.
Get your 3D BIM objects and start design HVAC control solutions.
Download
Modulating, high accuracy, geared actuator with field bus (BACnet MS/TP and Modbus RTU) connectivity used to control pressure independent balancing and control valves type AB-QM DN10-32. Control signal digital: BACnet MS/TP, Modbus RTUControl signal analog: 0-10V/2-10V, 0-20mA/4-20mA Direct connection to 6-port ball valve actuator with position feedback signal (*1)Direct connection to 2x PT1000 surface/immersed sensors and emission power indication (*2) Direct connection I/O: 2x resistance, AO and AI (*3)
Actuator functionality is remotely accessible via the field bus: - Design flow pre-setting - Flushing the valve and terminal unit - Error during closing intrinsic alarm reporting - Alarm if CO6 6-port ball valve actuator is blocked, in manual override or disconnected (*1) - Supply and return temperature readings, emission power indication (*2)- Energy counter (kWh, MJ, kBTU) (*2) - Alarm high/low deltaT and temperature sensors disconnected (*2) - Alpha characteristics setting - Speed selection 3/6/12/24 s/mm - Opening/closing time selection from 18s to 700s - Auto MAC addressing (BACnet only) - Auto Baud rate detection - Flow indication based on measured stroke in l/h Eu.bac interchangeability approved in combination with PIBCV valve Supply Voltage: 24V DC/AC 50/60Hz Spindle position accuracy: ±0.05mm Cables: Halogen free plug-in available in 1.5m, 5m and 10m length Temperature sensors: plug-in 2x PT1000 surface or immersed 1.5m length 64 actuators can be connected to the same network Supports BACnet service Change of Value (COV) Supports remote Firmware updates IP Class: 54 Stroke: 7mm BACnet Testing Laboratories (BTL) listed BACnet MS/TP fieldbus device (*4) Manual override function Configuration tool available easy configuration, commissioning and firmware updates Commissioning tool available for addressing, parametrization and hydronic continuous commission
Pulse input for Flow sensor to present real flow over the bus.Warnings via field bus for: No flow and flow out of expectationFull range from DN15-250.
Full range from DN15-250.(*1) CO6 application (*2) Energy application (*3) Remote I/O application (*4) Certification in Q2 2019
Modulating, high accuracy, geared actuator with bus connectivity used to control pressure independent control valves type AB-QM NovoCon® DN 40-100. Control signal digital: BACnet MS/TP, Modbus RTUControl signal analog: 0-10V/2-10V, 0-20mA/4-20mA Actuator functionality is remotely accessible via the fieldbus: - design flow pre-setting - flushing the valve and terminal unit - error during closing/opening/calibration alarm - LIN/LOG/α-setting characteristics setting - selectable speed - opening/closing time selection - auto MAC addressing (BACnet) - auto Parity detection (Modbus) - auto Baud rate detection - Flow and energy indication Supply Voltage 24V ac/dc 64 actuators can be connected to the same network IP Class: 54 Stroke: 20mm Manual override function Click on mounting LED status indication BACnet Testing Laboratories (BTL) listed BACnet MS/TP fieldbus device
Modulating, high accuracy, geared actuator with bus connectivity used to control pressure independent control valves type AB-QM DN125-150.
Control signal digital: BACnet MS/TP, Modbus RTU. Control signal analog: 0-10V/2-10V, 0-20mA/4-20mA
Actuator functionality is remotely accessible via the fieldbus:- design flow pre-setting- flushing the valve and terminal unit- error during closing/opening/calibration alarm- LIN/LOG/α-setting characteristics setting- selectable speed- opening/closing time selection- auto MAC addressing (BACnet)- auto Parity detection (Modbus)- auto Baud rate detection- Flow and energy indication- Safety function in NovoCon® L SU/SD. Spring up or spring down for AB-QM DN125-150 valves.
Supply Voltage 24V ac/dc
64 actuators can be connected to the same network
IP Class: 54
Stroke: 50 mm
Manual override function
LED status indication
Modulating, high accuracy, geared actuator with bus connectivity used to control pressure independent control valves type AB-QM DN200-250.
Actuator functionality is remotely accessible via the fieldbus:- design flow pre-setting- flushing the valve and terminal unit- error during closing/opening/calibration alarm- LIN/LOG/α-setting characteristics setting- selectable speed- opening/closing time selection- auto MAC addressing (BACnet)- auto Parity detection (Modbus)- auto Baud rate detection- Flow and energy indication
Modulating geared actuator used to control pressure independent balancing and control valves DN10-32.
*AME 110 NLX variant**AME 120 NL variant
3-point modulating geared actuator used to control pressure independent balancing and control valves DN 10-32.
*AMV 120 NL variant
Modulating thermal actuator used to control pressure independent balancing and control valves DN 10-32.
*LIN variant available**normally open variant available***6.5 mm variant available****24 V DC variant available
The actuators AME 435 QM for modulating control is used with pressure independent balancing and control valve type AB-QM from DN 40 to DN 100.
The actuator AME 55 QM is used with pressure independent balancing and control large valve type AB-QM DN 125 and DN 150.
AME 685-1 actuator is used together with large pressure independent balancing and control valves type AB-QM DN 200 and DN 250.
On/off thermal actuator used to control pressure independent balancing and control valves DN 10-32.
