SVL Flexline™ platform is expanded to 140 bar MWP to meet an increasing demand of large manual valves in industrial design for large scale R744 transcritical CO₂ systems.
The SVL-140 bar manual valve range for Industrial CO₂ Trans-critical Systems is based onthe successful modular Standard SVL platform. The same flexibility, simplicity and efficiencyare features offered in this series.
The valves are available in angle and straight connection. It is designed for favorable flow conditions and the FIA-140B can be fitted with the existing range of pleated filter inserts from 50 to 500 microns. Strainer inserts are shared with other FIA valves in the SVL platform.
The valves are especially applicable in medium and high-pressure part of the CO₂ transcritical system:
SVA-140B with balanced piston design providing smooth low torque opening of valve at high differential pressure
Straight and angle version valve body
Arrow for flow direction on valve body
Replaceable top part or filter insert
Buttweld and brazing connections
Max. working pressure: 140 bar (2030 psi)
A guide on servicing the Danfoss SVA-140 B shut-off valve. Watch the video on steps to ensure a safe and reliable valve operation.
Coolselector®2 features unbiased calculations for the selection of refrigeration and air conditioning components based on the user’s requirements or based on standard operating conditions.
Coolselector®2
AK-PC 782A is complete regulating units for capacity control of compressors and condensers in a transcritical CO2 booster system with parallel compressor.
ICMTS 50 & 80 for large capacity Transcritical CO2 systems. ICMTS platform is now expanding to larger sizes to meet an increasing demand of large Motorized valves in industrial design for large scale R744 transcritical CO2 systems.
ICM motor-operated valves, part of Danfoss' ICV Flexline™, regulate the expansion process in liquid lines and control pressure or temperature in wet and dry suction lines and hot gas lines. Compact and lightweight, ICM valves are easy to handle, install, and service.
The SVL Flexline™ 52 Bar product platform is targeted to meet industrial refrigeration requirements worldwide.
SVL Flexline™ platform is expanded to 140 bar MWP to meet an increasing demand of large manual valves in industrial design for large scale R744 transcritical CO2 systems.
