Pro-FX® configure software

Pro-FX^® Configure v2 is valve configuration software the way it should be: smarter, faster, easier. Featuring a wizard-based setup as well as parameter-based tuning, the user-friendly software enables quick and easy configuration of advanced AxisPro® valves.

A streamlined, step-by-step workflow takes the user through valve setup for specified control modes including spool position, cylinder position, pressure, speed, or force. The program simplifies everything from setup to tuning and commissioning, helping you get the machine to the customer faster.

Features

100% wizard-based setup
Parameter-based tuning
Expanded, improved alert library for diagnostics
Identifies firmware version and prompts update
Enhanced data plotting to help tune the application
No need to tune PID controller for most applications, saving time
Support for legacy versions of AxisPro firmware (7.x and 107.x)
Updated User Guide available on software download webpage
Updated release notes and known issue list included with software

AxisPro Valve Compatibility:

Model codes ending in -002-10: This version of Pro-FX is compatible with all valves having model codes ending with -002-10.

Model codes ending in -004-11: This Pro-FX version MUST be used to configure valves with model codes ending with -004-11.

For support inquiries, please send us an email.

Current Downloads

Prior Revisions

Supported CAN Card Drivers and Ethernet Tools

Below is a list of 3rd party drivers and tools used to configure and connect to devices supported by Pro-FX^®Configure.

Note: Driver versions newer those tested against Pro-FX^® Configure may not run correctly with Pro-FX^® Configure.

Driver name: CG150

Vendor	Danfoss
Website	Software and Tools
Used by Pro-FX^® Configure Platforms	AxisPro, CMA
Version Installed by and Tested Against ^® Configure	v2.2.1.0
Installation Notes	This is installed as a part of PLUS+1^® Update Center. To get updated drivers install PLUS+1^® Update Center. Click "Select Files Manually". Click "Edit". Then select CG150 under Files/Drivers. Install as usual with Update Center.

Driver Name: ECOM

Vendor	CANCapture
Website	https://www.cancapture.com/cancapture
Used by Pro-FX^® Configure Platforms	AxisPro, XFX
Version Installed by and Tested Against Pro-FX^® Configure	v3.3.0.0
Installation Notes	Download the latest driver from the section entitled “Latest Driver Installation.” This will download the driver installation program. Run the program after it's downloaded.

Tool Name: Hilscher Ethernet Device Configuration Tool

Vendor	Hilscher
Website	https://hilscher.atlassian.net/wiki/spaces/ETHDEVCFG/overview
Used by Pro-FX^® Configure Platforms	AxisPro
Version Installed by and Tested Against Pro-FX^® Configure	v1.0900.3.5506
Installation Notes	Click the download link for the "current release" and follow the download instructions on the page you're brought to.

Driver name: Kvaser

Vendor	Kvaser
Website	https://kvaser.com/download/
Used by Pro-FX^® Configure Platforms	AxisPro, CMA, XFX
Version Installed by and Tested Against Pro-FX^® Configure	v5.22.392.0
Installation Notes	Click "Download" in the "Kvaser Drivers For Windows" section to navigate to the download page. Then download the version of the driver installation program you want (usually the most recent). Run the downloaded installation program.

Driver Name: PCAN

Vendor	PEAK-System
Website	Drivers: PEAK-System
Used by Pro-FX^® Configure Platforms	AxisPro, CMA, KBDG, KBFRG4, XFX
Version Installed by and Tested Against Pro-FX^® Configure	v4.1.3.202
Installation Notes	Click "Device Driver Setup Windows 11 (x86ARM64), 10 (x64)" to download a zip file containing the driver. Unzip the zip file then run the installation program.

Driver Name: Softing

Vendor	Softing AG
Website	Downloads \| Softing
Used by Pro-FX^® Configure Platforms	AxisPro, CMA, XFX
Version Installed by and Tested Against Pro-FX^® Configure	v5.21
Installation Notes	Select from the lists presented on the webpage. First, select the following in the three list boxes from left to right: 1) CAN/CANopen 2) USB and Bluetooth Modems 3) CANpro USB – CAN Single Channel USB Interface Card. Next click the “SHOW” button under the “Product” list. Then click the Windows Driver link. It will resemble the following: “CAN Driver, API, Manual, LeanCANopen Programming Samples Windows 10/Windows 8/Windows 7 V5.23.1”. You will be prompted to login before you can download the driver.

Driver Name: ValueCAN

Vendor	Intrepid Control Systems
Website	Support Resources \| Intrepid Control Systems, Inc. (intrepidcs.com)
Used by Pro-FX^® Configure Platforms	AxisPro, KBDG, KBFRG4
Version Installed by and Tested Against Pro-FX^® Configure	v3.9.14.15
Installation Notes	Click the link named "ICS Hardware Installation kit" to download a zip file containing the driver installation program. Unzip the file and run the installer.

Documents

Documents
Type	Name	Language	Valid for	Updated	Download	File type
Operating guide	Pro-FX Configure KBSD14, KBFD/TG4 & KBHD15 Configuration & Commissioning Guide	English	Multiple	16 Oct, 2025	3.7 MB	.pdf
Operating guide	Pro-FX Configure KBSD14, KBFD/TG4 & KBHD15 Configuration & Commissioning Guide	English	Multiple	23 Sep, 2025	3.3 MB	.pdf
Fact sheet	Vickers by Danfoss Pro-FX Configure v2 - Where configurability meets simplicity fact sheet	English	Multiple	13 Nov, 2023	1.3 MB	.pdf
User guide	Vickers by Danfoss Pro-FX Configure v2 software for AxisPro platform user guide	English	Multiple	25 Oct, 2023	3.1 MB	.pdf
