EHPS steering valves

EHPS

Proven technology for high flow rates

The EHPS steering valve is the classic choice for applications requiring high flow rates and maximum integration. Large machines like articulated steering tractors, dumpers and loaders benefit from the flexibility of the EHPS.

It utilizes the potential from the full range of electronic steering controllers as PVES, PVED CC and PVED CLS to provide electrohydraulic steering functionality such as joystick steering and auto-guidance.

Features and benefits

OEMs

Steer-by-Wire technology, for applications requiring high flow rates
Integrated safety and steering controller with interface to Auto guidance (GPS), joystick
and electric steering wheel
Proven technology that accelerates your time to market
Compliant with all current legislations and safety standards – SIL 2, AgPLd, Cat 3
Integrated priority valve, or flanged using OLS320 or PVG proportional valves
Electric disengage of electrohydraulic steering e.g. Auto guidance (GPS)
Steering pressure up to 250 bar
Flow capacity up to 100 l/min

Operators

Superior steering performance and safety with precise handling and control under all conditions
Increased productivity with auto-guidance (GPS) steering and variable steering ratio (quick steering)
Improved operator comfort with joystick and electric steering wheel

Documents

Documents
Type	Name	Language	Updated	Download	File type

Related products

OSPE

Electro-hydraulic steering valve used with mechanical steering wheel. Certified - SIL 2 fail safe. Applications with quick steering and auto-guidance (GPS). Interface to joystick and electric steering wheel.

EHi

Electro-hydraulic steering valve used for steer-by-wire systems. Certified - SIL 2 fail safe. Applications with quick steering, auto-guidance (GPS) and all wheel steering. Interface to joystick and electric steering wheel.

e-Wheel 100

Electric steering wheel input device with passive force-feedback used for steer-by-wire systems. Certified - SIL 2 fail safe. Improving operator comfort and ergonomics. Variable steering ratio and smooth steering feel.

SASA sensors

Steering wheel sensor is used to detect the absolute position and speed of a mechanical steering wheel. Used in applications with variable steering ratio and closed loop set-ups where steering wheel position and vehicle steering angle have to match.
